2006 Jeep WK Grand Cherokee Limited Edition Specifications and Features

Features, Options and Colors

Welcome to the JeepSpecs.com in-depth page on the 2006 WK Generation Jeep Grand Cherokee limited edition specifications and features. Did we miss anything? Please get in touch with us and tell us about it!





2006 Limited Standard Features

(Key features are noted in BOLD
  • 12V AUXILIARY POWER OUTLET (JKP)
  • 140 MPH PRIMARY SPEEDOMETER (JCE)
  • 160 AMP ALTERNATOR (BAB)
  • 17X7.5 ALUMINUM WHEELS (WGQ)
  • 20.5 GALLON FUEL TANK (NFP)
  • 200MM FRONT AXLE (DJA)
  • 213MM REAR AXLE (DRS)
  • 276 WATT AMPLIFIER (RD7)
  • 3.73 AXLE RATIO (DME)
  • 4X4 BADGE (MWT)
  • 50 STATE EMISSIONS (NAS)
  • 6 BOSTON ACOUSTICS SPEAKERS (RC6)
  • 730 AMP MAINTENANCE FREE BATTERY (BCN)
  • AM/FM CD 6-DISC MP3 RADIO (RAQ)
  • ADJUSTABLE ROOF RAIL CROSSBARS (MWF)
  • ADVANCED MULTISTAGE FRONT AIR BAGS** (CG3)
  • AIR COND ATC W/DUAL ZONE CONTROL (HAF)
  • ANTI-LOCK 4-WHEEL DISC BRAKES (BRY)
  • AUTOMATIC HEADLAMPS (LMG)
  • BLACK WINDSHIELD MOLDINGS (MHA)
  • BODY COLOR FASCIAS W/BRIGHT INSERT (MCX)
  • BODY COLOR LICENSE PLATE BROW (MNN)
  • BRIGHT BELT MOLDINGS (MMS)
  • BRIGHT GRILLE (MFZ)
  • CHMSL LAMP (LPS)
  • CARGO COMPARTMENT CARPET (CKN)
  • CARGO COMPARTMENT COVER (CSC)
  • CARGO COMPARTMENT LAMP (LDB)
  • CARGO CONVENIENCE GROUP (AWF) (ROOF RAIL CROSSBARS & CARGO COVER)
  • CARGO TIE DOWN LOOPS (CKT)
  • CARGO TRIM PANEL W/STORAGE NET (CLH)
  • CENTER REAR 3-POINT SEAT BELT (CG6)
  • CHILD SEAT ANCHOR SYSTEM-LATCH READY (CGU)
  • CHILD SEAT UPPER TETHER ANCHORAGES (CF4)
  • CHROME BODYSIDE MOLDING (MJB)
  • CLOTH COVERED HEADLINER (CHB)
  • CONVENTIONAL DIFFERENTIAL FRT AXLE (DS7)
  • CONVENTIONAL DIFFERENTIAL REARAXLE (DS8)
  • COURTESY LAMPS (LBB)
  • DEEP TINT SUNSCREEN GLASS (GEG)
  • DELUXE INSULATION GROUP (HGD)
  • DUAL NOTE ELECTRIC HORNS (JJB)
  • ENGINE – 4.7L V8 MPI ENGINE (EVA)
  • ELECTRONIC STABILITY PROGRAM (BNB)
  • EMERGENCY BRAKE ASSIST (BGE)
  • ENHANCED ACCIDENT RESPONSE SYSTEM (LSE)
  • FEDERAL TIER 2, BIN 8A EMISSIONS (NBE)
  • FIXED LONG MAST ANTENNA (RDD)
  • FLIPPER LIFTGATE GLASS (GEP)
  • FLOOR CARPET (CKD)
  • FOG LAMPS (LNJ)
  • FOUR WHEEL TRACTION CONTROL (BNR) (N/A with Quadra-Drive)
  • FRONT & REAR FLOOR MATS (CLE)
  • FRONT DOOR TINTED GLASS (GCB)
  • FRONT LICENSE PLATE BRACKET (MDA)
  • FULL LENGTH FLOOR CONSOLE (CUF)
  • FULL SIZE MATCHING WHL SPARE TIRE (TBW)
  • GVW RATING – 6100# (Z6B)
  • GLOVE BOX LAMP (LBC)
  • HALOGEN HEADLAMPS (LMB)
  • HEATED FRONT SEATS (JPM)
  • HEAVY DUTY ENGINE COOLING (NMC)
  • HOOD INSULATION (HGA)
  • ILLUMINATED ENTRY (LAC)
  • INSTRUMENT CLUSTER W/TACH (JAY) (gray faced with chrome trim rings)
  • INSTRUMENT PANEL (JAP)
  • JEEP BADGE (MVC)
  • LEATHER TRIMMED BUCKET SEATS (*PL)
  • LEATHER WRAPPED STEERING WHEEL (SCL)
  • LIMITED BADGE (MVA)
  • LOCK-UP TORQUE CONVERTER (DHA)
  • LOCKING GLOVE BOX (JKA)
  • LOW BACK BUCKET SEATS (CAC)
  • MANUAL DRIVER & PASS LUMBAR ADJUST (CDU)
  • MONOTONE PAINT (APA)
  • NORMAL DUTY SUSPENSION (SDA)
  • OCCUPANT CLASSIFICATION SYSTEM (XCA)
  • OVERHEAD CONSOLE (CUN)
  • P245/65R17 OWL ALL TERRAIN TIRES (TCD)
  • PASSENGER ASSIST HANDLES (CSR)
  • POWER ACCESSORY DELAY (JKY)
  • POWER ADJUSTABLE PEDALS W/MEMORY (XAM)
  • POWER LOCKS (JPB)
  • POWER RACK AND PINION STEERING (SBA)
  • POWER STEERING COOLER (NHF)
  • PREMIUM DOOR TRIM PANEL (CBF)
  • PROTECTIVE COATING AND REMOVER (XPF)
  • PWR 8-WAY DRVR MEM 4-WAY PASS SEATS (JPK)
  • PWR FRONT WINDOWS, 1-TOUCH,UP & DOWN (JP3)
  • PWR HEAT MEMORY FOLDING AUTO MIRRORS (GUD)
  • QUADRA-TRAC II FULL-TIME, ACTIVE 4WD (DHX)
  • RADIO/DRIVER SEAT/MIRRORS MEMORY (LEW)
  • RAIN SENSITIVE WINDSHIELD WIPERS (JHC)
  • REAR 60/40 FOLDING SEAT (CFN)
  • REAR COURTESY/READING LAMPS (LCE)
  • REAR POWER OUTLET (JJM)
  • REAR VIEW AUTO DIM MIRROR (GNK)
  • REAR WINDOW DEFROSTER (GFA)
  • REAR WINDOW WIPER/WASHER (JHB)
  • REMOTE KEYLESS ENTRY (GXM)
  • REVERSIBLE/WATERPROOF CARGO STORAGE (CL5)
  • SECURITY ALARM (LSA)
  • SENTRY KEY THEFT DETERRENT SYSTEM (GXX)
  • SIDE ROOF RAILS (MWE)
  • SILL MOLDING (K50)
  • SMARTBEAM HEADLAMPS (LMS)
  • SPEED CONTROL (NHM)
  • STEERING WHEEL MOUNTED AUDIO CTRLS (RDZ)
  • SUN VISORS W/ILLUM VANITY MIRRORS (GNC)
  • TRANSMISSION – 5-SPD AUTOMATIC 5-45RFE
  • TILT STEERING COLUMN (SUA)
  • TINTED WINDSHIELD GLASS (GBB)
  • TIRE PRESSURE MONITORING DISPLAY (XGM)
  • TRAIL RATED BADGE (MT2)
  • TRAVELER/MINI TRIP COMPUTER (LET)
  • UNIVERSAL GARAGE DOOR OPENER (XGD)
  • VEHICLE INFORMATION CENTER (LAZ)
  • WARNING CHIME (LAG)



2006 Limited Optional Features
  • Limited 25K Package

Includes:
Elec ltd slip differential front axle (DSG)
Elec ltd slip differential rear axle (DSF)
ParkSense rear back-up system (XAA)
Power sunroof (GWA)
Quadra-Drive 4wd system (AWB)
Sirius satellite radio (RSA) with 1-year service (X97)

Additional options:



  • 5.7L HEMI MULTI DISPLACEMENT ENGINE (EZB)
  • 17X7.5 ALUMINUM CHROME CLAD WHEELS (WGX)
  • 6CD/FULL MAP GPS DISPLAY NAV RADIO (REC)
  • ENGINE BLOCK HEATER (NHK)
  • P235/65R17 BSW AS PERF TIRES (TWG)
  • PARKSENSE REAR BACK-UP SYSTEM (XAA)
  • POWER SUNROOF (GWA)
  • SIRIUS SATELLITE RADIO (RSA)
  • SKID PLATE GROUP (ADL) (Front, T-case and Fuel tank, plus Tow Hooks)
  • SUPPLEMENTAL SIDE AIR BAGS (CGS)
  • TRAILER TOW GROUP IV (AHX)
  • UCONNECT HANDS-FREE COMMUNICATION (RSP)



  • ELECTRONIC INFOTAINMENT SYS GROUP (AEK)


Includes:
DVD screen in overhead console
DVD player located in center floor console
Includes 2 wireless headphones and remote control
Includes capability to play cd music thru the headphones

2006 Interior Colors

2006 Limited Exterior Colors
Color Paint
Code
Sales
Code
Mopar
Brush p/n
Mopar
Spray p/n
Sherwin
Williams
 Light Khaki Metallic Clear Coat AJC PJC 05083325AA 05083326AA 64023
 Dark Khaki Pearl Coat BJT PJT 04889945AA 04889946AA 66928
 Deep Beryl Green CGV PGV 04889949AA 04889950AA 67074
 Inferno Red Crystal Pearl Coat   PRJ
 Bright Silver Metallic Clear Coat WSB PSB 05013709AA 05013710AA 57270
 Black Clear Coat   PX8
 Stone White Clear Coat SW1 PW1 04864104 04864105 51539
 Midnight Blue Pearl Coat BB8 PB8 04889866AA 04889867AA 64944
